Thread: 143eldx vs 147eldm

  1. #1
    DBD
    DBD is offline
    Member DBD's Avatar
    Join Date
    Aug 2018
    Location
    Canterbury
    Posts
    862

    143eldx vs 147eldm

    So what's the difference, my readings on the world wide web recons much of a muchness between the two although a slight difference in size and ogive.
    Anyone use both in the same rifle, any performance difference?

  2. #2
    Member
    Join Date
    Aug 2018
    Location
    Christchurch
    Posts
    1,488
    @Steelisreal can probably chime in here.

    I'm led to believe they're the same size and shape but the M's have a thinner jacket and less of a HP so less copper and more lead to make up the extra 4 grains.

    I've got two rifles that like the M's. Have never tried the X's.

    Obvious performance difference is the difference in BC. Terminal performance: the M's will be a bit softer.
    Resident 6.5 Grendel aficionado.

  3. #3
    Member
    Join Date
    Jan 2018
    Location
    Christchurch
    Posts
    658
    Quote Originally Posted by Pommy View Post
    @Steelisreal can probably chime in here.

    I'm led to believe they're the same size and shape but the M's have a thinner jacket and less of a HP so less copper and more lead to make up the extra 4 grains.

    I've got two rifles that like the M's. Have never tried the X's.

    Obvious performance difference is the difference in BC. Terminal performance: the M's will be a bit softer.
    That pretty much sums up what I know as well.

    They might be the same shape but they definitely behave very differently. I've had great success with the 143 Eld-X - shoots very small groups repeatedly with Re16.

    The same can't be said for the 147 - haven't found the magic recipe as yet.

    I've shot a pile of small to medium sized critters with the Eld-X and they worked well. I've only fired four at deer so far. The first one was a complete miss, many lessons learnt. Next three have all dropped a deer each so no complaints at all.
    janleroux likes this.

  4. #4
    Member
    Join Date
    Jul 2017
    Location
    Whangarei
    Posts
    1,085
    NB word also is that the thicker jacket on the X is inclined to push up pressures,

    ie don't take the load data for the heavier M and expect to use it for the X.
    Z

  5. #5
    Member
    Join Date
    Apr 2017
    Location
    The 'Naki
    Posts
    2,103
    So does M not stand for Match - i.e. X is a hunting projectile, M is a paper puncher?

    https://www.hornady.com/bullets/eld-match#!/

    Or am I stating the obvious, missing the question?

  6. #6
    Member
    Join Date
    Aug 2018
    Location
    Christchurch
    Posts
    1,488
    Quote Originally Posted by Jhon View Post
    So does M not stand for Match - i.e. X is a hunting projectile, M is a paper puncher?

    https://www.hornady.com/bullets/eld-match#!/

    Or am I stating the obvious, missing the question?
    Those are their stated purposes as per Hornady, yes. The M's certain don't bounce off of deer though. They're both jacketed hollowpoints with polymer tips when you cross section them.
    Jhon likes this.
    Resident 6.5 Grendel aficionado.

  7. #7
    Member
    Join Date
    Apr 2017
    Location
    The 'Naki
    Posts
    2,103
    So are Ms commonly used for hunting? Or just when needs must?

  8. #8
    Member
    Join Date
    Aug 2014
    Location
    Palmerston North
    Posts
    909
    Quote Originally Posted by Jhon View Post
    So are Ms commonly used for hunting? Or just when needs must?
    Quite common yes. Often used for long rang hunting applications as when impact velocity decreases the softer ELD-M expands quite reliability and creates good wound chanels. Some harder purpose built hunting projectiles leave the risk of not having enough expansion if no bone is hit at longer ranges.

    Also a lot of people(including myself) use the match model(still going on the 162 amax) in short bushpig setups. Driven at moderate speeds they are very effective close range projectiles and still retain enough energy and expansion abilitues to shoot out to 500m ish- give or take depending on shooter ability, load consistency etc.
    Jhon likes this.

  9. #9
    Sending it Gibo's Avatar
    Join Date
    Feb 2013
    Location
    The Hill
    Posts
    23,164
    Quote Originally Posted by Jhon View Post
    So are Ms commonly used for hunting? Or just when needs must?
    The use of M's these days would have stemmed from the extensive and successful use of the old AMAX. Which was in fact by design a match projectile but good old Kiwi's turned it into a deer slayer with a cult following, ever heard of AMAXED?
    buzzman, wsm junkie, 199p and 1 others like this.

  10. #10
    Member
    Join Date
    Aug 2018
    Location
    Christchurch
    Posts
    1,488
    Here's the exit on a fallow hit with a 7mm 180 ELD-M.

    Name:  20210516_114442.jpg
Views: 241
Size:  4.94 MB

    The M's do just fine, even up close, provided they aren't pushed too hard.
    keengunNic and Jhon like this.
    Resident 6.5 Grendel aficionado.

  11. #11
    DBD
    DBD is offline
    Member DBD's Avatar
    Join Date
    Aug 2018
    Location
    Canterbury
    Posts
    862
    @Steelsreal
    Ive been shooting 130gr TGK in a 6.5 creedmoor 22" barrel with very good accuracy and velocities using Rl16. Im looking to change to something a bit heavier for hunting use and have a heap of 143eldx. What's your load and rifle setup for the 143 just for interest not to copy it.

  12. #12
    Member
    Join Date
    Jul 2019
    Location
    Auckland
    Posts
    1,180
    @Pommy what is pushing too hard ? 3000fps?

    Quote Originally Posted by Pommy View Post
    Here's the exit on a fallow hit with a 7mm 180 ELD-M.

    Attachment 176038

    The M's do just fine, even up close, provided they aren't pushed too hard.

  13. #13
    Member 199p's Avatar
    Join Date
    Dec 2011
    Location
    Palmerston North
    Posts
    4,074
    General rule of thumb

    Heavy projectile for case then M
    Light projectile for case then X
    veitnamcam and Jhon like this.
    Konus binoculars " The power to imagine"

  14. #14
    Member stagstalker's Avatar
    Join Date
    Jul 2018
    Location
    North Island, New Zealand
    Posts
    2,120
    No experience with the 6.5s sorry but I have used both the 7mm 162 M and X plenty on deer.

    The difference in terminal performance is much of a muchness. They are both great killers. The M a little more savage but never had any issues.

    They are definitely different pills. The X is longer with more bearing surface with a larger tip where as the M is a touch smaller with a smaller tip. My experience is the 162 X induces higher pressures sooner, I assume due to the increased bearing surface and thicker jacket.

  15. #15
    Member
    Join Date
    Aug 2014
    Location
    Palmerston North
    Posts
    909
    Quote Originally Posted by 308mate View Post
    @Pommy what is pushing too hard ? 3000fps?
    @308mate difference in intended ranges would be my deciding factor when doing a load development. I tend to think more about impact velocity when used for hunting applications. Eg a 7mm mag, capable of taking deer par 7-800m, anything north of 3000fps for 162eldm is more desirable, however, my 7mm08 with same 162eldm i aimed for 2650fps for more appropriate impact velocities at closer ranges
