Thread: What tool to cut corrugated Iron

  1. #16
    Member Savage1's Avatar
    Join Date
    Dec 2011
    Posts
    2,345
    I put a roof on our house a year or so ago.

    Do they have to be perfectly straight edges? If they're covered ph a flashing or capping then the easiest and quickest way is to snip in a ridge or two then stand in one edge and pull the other edge up, it tears very easily but isn't perfectly straight.

    Otherwise tinsnips, I've got an almost new pair of large Gilbows that you can borrow, provided I get them back. Other wise get a red and green handled pair.

    I used a bubbler for a while but unless they're angled cuts then they're not needed, hard to cut straight with too.

    No experience with power shears. All of the roofers I spoke to either use snips or tear it.

  2. #17
    Member Savage1's Avatar
    Join Date
    Dec 2011
    Posts
    2,345
    Do not use a angle grinder, as said above, it stuffs it.

  3. #18
    Member
    Join Date
    Nov 2015
    Location
    Wanganui no H
    Posts
    232
    LIke @Munsey said good pair of Gilbows will be your best bet. Gives good clean edge and saws will swarf with the hot bits wreaking your finish. @Savage1 Red and Green Avi shears and Left and Right cutting. Yellow are straight cut aviation shears.

  4. #19
    Member
    Join Date
    Nov 2014
    Posts
    1,601
    Quote Originally Posted by Savage1 View Post
    I put a roof on our house a year or so ago.

    Do they have to be perfectly straight edges? If they're covered ph a flashing or capping then the easiest and quickest way is to snip in a ridge or two then stand in one edge and pull the other edge up, it tears very easily but isn't perfectly straight.

    Otherwise tinsnips, I've got an almost new pair of large Gilbows that you can borrow, provided I get them back. Other wise get a red and green handled pair.

    I used a bubbler for a while but unless they're angled cuts then they're not needed, hard to cut straight with too.

    No experience with power shears. All of the roofers I spoke to either use snips or tear it.
    Hi

    Thank you for the offer. Seing as so many suggest the Gilbows and looking at the hardware stores these dont seem to be expensive, I might just get a pair of those for myself. Thank you all.

    Next question is where is the best value in Chch for these? And are ther any that I should avoid?

    I am making a garden shed so flashing use will be minimal but its going to be a dam good shed. I will post images up when I have them of a progress in a new thread....in case anyone decides they like the idea of what I have done....

  5. #20
    Member
    Join Date
    Nov 2014
    Location
    Central Otago
    Posts
    382
    Here is an old carpenters trick for cutting corrugated iron lengthwise. Determine where the cut is to be made and make sure you turn the sheet over if required to get the cut in the bottom of a corrugation. Take a sharp cross-cut saw and hold it backwards (front of blade towards your body) and position the last tooth at the edge of the iron. Lift the front of the blade a couple of inches and hold it firmly (a bit of rag helps protect your hand), push firmly down on the top of the saw handle and drag the tooth down the full length of the corrugation. The tooth should make a deep scratch and it is important to keep it as one continuous gouge down the centre of the corrugation. Turn the sheet over and fold it back along the groove a couple of times and it will fracture neatly. Caution; the edges will be sharp! This is miles quicker and much safer than trying to use tin snips.
    P38 and Munsey like this.

  6. #21
    Member
    Join Date
    Nov 2014
    Posts
    1,601
    Quote Originally Posted by gundoc View Post
    Here is an old carpenters trick for cutting corrugated iron lengthwise. Determine where the cut is to be made and make sure you turn the sheet over if required to get the cut in the bottom of a corrugation. Take a sharp cross-cut saw and hold it backwards (front of blade towards your body) and position the last tooth at the edge of the iron. Lift the front of the blade a couple of inches and hold it firmly (a bit of rag helps protect your hand), push firmly down on the top of the saw handle and drag the tooth down the full length of the corrugation. The tooth should make a deep scratch and it is important to keep it as one continuous gouge down the centre of the corrugation. Turn the sheet over and fold it back along the groove a couple of times and it will fracture neatly. Caution; the edges will be sharp! This is miles quicker and much safer than trying to use tin snips.
    I will give that a try too. Thanks Gundoc. I have a few sheets I will need to rim lenghth ways...

  7. #22
    Member
    Join Date
    Feb 2013
    Location
    spreydon christcurch.
    Posts
    2,911
    i go ta metal guarded skilsaw and put an 8"metal cutting disc in it .iron was nailed on so just marked the cut then went for it -no wuckin furries!make sure youre wearin full protective gear though .Have used jigsaw as well but its a tad slow!

  8. #23
    GSP Mad Munsey's Avatar
    Join Date
    Mar 2012
    Location
    Christchurch
    Posts
    5,056
    Quote Originally Posted by gundoc View Post
    Here is an old carpenters trick for cutting corrugated iron lengthwise. Determine where the cut is to be made and make sure you turn the sheet over if required to get the cut in the bottom of a corrugation. Take a sharp cross-cut saw and hold it backwards (front of blade towards your body) and position the last tooth at the edge of the iron. Lift the front of the blade a couple of inches and hold it firmly (a bit of rag helps protect your hand), push firmly down on the top of the saw handle and drag the tooth down the full length of the corrugation. The tooth should make a deep scratch and it is important to keep it as one continuous gouge down the centre of the corrugation. Turn the sheet over and fold it back along the groove a couple of times and it will fracture neatly. Caution; the edges will be sharp! This is miles quicker and much safer than trying to use tin snips.
    Still done today but an easier way to do it is use a Stanly knife , brake the tip off (3mm) . It's easier to hold and controll & really tears into the iron . Roofers use the battery power sheers now .

    Sent from my SM-G930F using Tapatalk
    Rule 7: Avoid alcohol and drugs when handling firearms

  9. #24
    Member Gapped axe's Avatar
    Join Date
    Jun 2012
    Location
    Lake Tarawera
    Posts
    2,958
    14'' Gilbows
    "ars longa, vita brevis"

  10. #25
    Huk
    Huk is offline
    Member
    Join Date
    Mar 2015
    Location
    Parua Bay Nthld
    Posts
    280
    Quote Originally Posted by 2Quack View Post
    +1 for tin snips and ripping it with gloves
    Your onto it 2quack + a boot on it for across corros easy n fast

  11. #26
    Member sako75's Avatar
    Join Date
    Dec 2011
    Location
    Supercity
    Posts
    4,384
    Got a roofing mate. As Munsey said, a cutoff wheel is a big no no

  12. #27
    Member
    Join Date
    Oct 2013
    Location
    Western BoP
    Posts
    1,238
    Cordless grinder with the megaline 1mm or the new fangled 0.9mm discs.

    I just closed in the front of my lean to with 6-rib iron, every sheet had to be cut at angles etc and did the whole job on two discs and two battery charges. The reason for changing the discs was not that they were stuffed, but that even a little wear means you can't get to the other side of the iron in one pass...

    Way easier quicker and I would suggest safer than a lot of other methods, mark and grind cut done.

    Have used nibblers, metal blades with diamond and tungsten, hand shears, scorers, snips etc etc and that is by far the easiest and quickest way just be aware of the odd flying electric flea not ideal if they get in your eyeballs.

  13. #28
    Member Cordite's Avatar
    Join Date
    May 2017
    Location
    NZ Mainland
    Posts
    452
    Same as you use for A-cat safes.
    Guns don't kill people - cars do.

  14. #29
    Member
    Join Date
    Jun 2015
    Location
    christchurch
    Posts
    2,181
    i find this a quick method of cutting corrugated iron, takes a while to file the edges clean thoughName:  34e3eb5f-76a8-4dc5-999b-1b4505319d14.jpg
Views: 61
Size:  28.1 KB
